Alkaline Electrolyzer

Cost reduction of green hydrogen produced by water electrolysis is highly desirable to reduce the costs of the energy transition. This not only requires low-cost green electricity, but also lower capital costs. The latter is especially important, since the future electrolysis plants will be operated based on (excess) variable renewable electricity limiting the number of operating hours and hence increasing the relatively contribution of capital costs. There are three ways to drive down the capital costs: economies of scale, economies of numbers and innovation.
"Economies of scale" means that large plants are relatively cheaper. In the chemical industry it is a typical that a plant that is ten times bigger is only five times more expensive, implying that the capital costs per unit of product produced are a factor two lower. A question is whether this scaling will also apply to electrolysis plants, since electrolyzers do not "scale well": due to limitations in heat management current alkaline stacks are limited to approximately 10 MW in size and this number is not expected to increase much in the future. This means that for larger plants the electrolyzers will just need to be "numbered up", implying that there are limited scale advantages for electrolyzers. At the same time, the stacks only contribute 10-20% of the total plant costs and the other 80-90% of the costs scale well. Therefore, we still expect good economies of scale for water electrolysis plants, although they might be slightly less favourable than for normal chemical plants.
"Economies of numbers" means that when more units of the same product are produced, they become cheaper because of automated manufacturing and other optimizations of the supply chain. The best-known example are solar panels where huge cost reductions have been achieved in this way. Also, in the field of electrolyzers there is huge potential for "economies of scale", since currently most electrolyzers are still made in a very labour-intensive way with manual assembly of cells into stacks. Due to the increasing demand for electrolyzers we already see manufacturers start developing automated production lines leading to a significant cost reduction.
Both "economies of scale" and "economies of numbers" will contribute to cost reduction, but there is also a trade-off between them: larger stacks and modules (which include a.o. pumps, gas-liquid separators, and heat exchangers) imply that the number of units will be lower and hence the advantages of "economies of numbers" will be smaller. However, the water elecrolyzer market will be so large that even with large stacks and modules there will still be significant "economies of numbers". This makes that for water electrolysis "economies of scale" and "economies of numbers" can be complementary.
Another major driver for cost reduction will be innovation. Although alkaline technology already exists for over 100 years, there is still ample room for technical innovations, especially regarding the current density at which the technology is operated. Compared to traditional alkaline electrolysis technology, the current density can be increased by over a factor five through innovations in the diaphragm, electrode coatings and cell design. Figure 3 shows a schematic representation of a conceptual alkaline electrolysis stack that could be on the market in 2030. Table 2 shows the corresponding performance characteristics of such an electrolyzer, showing that the hydrogen output of such an electrolyzer can be a factor ten higher than traditional alkaline electrolyzers. This effectively reduces the costs of the produced hydrogen, since the stack is not ten times more expensive that the traditional one.

There are many ways in which hydrogen production electrolysis can benefit individuals as well as businesses. Perhaps the main advantage of this technique involves the production of green hydrogen as opposed to relying upon blue hydrogen (a product derived from traditional fossil fuel sources such as natural gas). In other words, an electrolyzer offers a renewable means to produce energy.

It is therefore clear to see why an electrolyzer is often used within the hydrogen fuel cell industry. This gas can be collected and stored in order to recharge cells once they become depleted; dramatically extending their lifespan while ensuring reliable sources of energy.

Another interesting application involving hydrogen storage involves how it can be integrated into existing green technologies. For example, there can be times when wind turbines are unable to produce sufficient levels of power due to weather conditions. An on-site electrolyzer can be employed as a redundant system.

Another instance involves situations when an excess amount of mains electricity is produced. As opposed to curtailing production, this power can be redirected to an electrolyzer; resulting in more adequate stores of hydrogen for future use.[9]

Alkaline electrolysis of water stands out for its exceptional scalability, adapting effortlessly to diverse hydrogen production needs. This versatility makes it applicable across a spectrum of scenarios, from modest-scale initiatives to expansive industrial processes. Additionally, the extended operational lifespan of alkaline electrolysis ensures a consistent and sustainable hydrogen supply over an extended duration.
The cost-effectiveness of alkaline electrolysis is another notable advantage, with its equipment requiring less expensive materials compared to alternative hydrogen production methods. This affordability broadens its accessibility, extending its appeal to a diverse user base, including small enterprises and research institutions.

Simplicity defines the maintenance of alkaline electrolysis systems. Their straightforward design demands minimal attention and service, eliminating the necessity for specialized skills or costly maintenance routines, establishing it as a convenient choice for hydrogen production.

Operating at lower temperatures is a key benefit of alkaline electrolysis, contributing to reduced energy consumption and heightened overall efficiency. This energy-efficient process results in cost savings and a diminished environmental footprint.
High-purity hydrogen production is an additional merit of alkaline electrolysis, particularly crucial for applications in industries such as fuel cells and chemicals. The assurance of top-tier performance and reliability in these sectors solidifies alkaline electrolysis as a preferred method for hydrogen production.

Finally, the eco-friendly potential of alkaline electrolysis is noteworthy. By integrating renewable energy sources like solar or wind power, the process significantly curtails carbon emissions and diminishes reliance on fossil fuels, aligning with the overarching goal of fostering a sustainable and environmentally conscious energy system.

In summary, alkaline electrolysis of water offers a multifaceted array of advantages for hydrogen production. Its scalability, cost-effectiveness, low-maintenance attributes, ability to operate at lower temperatures, high-purity hydrogen output, and eco-friendly characteristics position it as a compelling solution across various applications. Whether deployed in small-scale projects or large-scale industrial settings, alkaline electrolysis of water emerges as a dependable and sustainable source of hydrogen.

An alkaline electrolyzer is a device that uses an electrolyte solution, typically potassium or sodium hydroxide, to split water molecules into hydrogen and oxygen through a process called electrolysis. The chemical principle behind an alkaline electrolyzer is based on the principles of electrochemistry. In electrochemistry, chemical reactions are driven by the transfer of electrons from one substance to another. When an electrical current is applied to an electrolyte solution, it causes the electrolyte solution to undergo a process called electrolysis. During this process, the electrical current causes the water molecules to be split into their constituent atoms of hydrogen and oxygen.
In an alkaline electrolyzer, the process is made possible by the presence of the electrolyte solution, which contains hydroxide ions (OH-) that facilitate the transfer of electrons between the electrodes and the water molecules. The hydroxide ions are attracted to the positively charged anode (the electrode connected to the positive terminal of the power source) and the hydrogen ions (H+) are attracted to the negatively charged cathode (the electrode connected to the negative terminal of the power source).
At the anode, water molecules are oxidized to form oxygen gas and positively charged hydrogen ions: 2H2O → O2 + 4H+ + 4e-
At the cathode, hydrogen ions are reduced to form hydrogen gas: 4H+ + 4e- → 2H2
Overall, the reaction can be expressed as: 2H2O → 2H2 + O2
The electrolyte solution plays an important role in the process by providing a conductive medium for the flow of electrons between the electrodes and the water molecules. The hydroxide ions in the electrolyte solution also help to maintain a stable pH level, which is important for the efficient functioning of the electrolyzer.
In summary, an alkaline electrolyzer works by using an electrolyte solution to facilitate the transfer of electrons between the electrodes and the water molecules, resulting in the production of hydrogen and oxygen gas.

Alkaline electrolyzers are typically constructed using materials that are resistant to corrosion and can withstand the harsh conditions of the electrolysis process. The main materials used in alkaline electrolyzers include:

Electrodes: The electrodes in alkaline electrolyzers are typically made of nickel, nickel-plated steel, or titanium coated with a nickel-based alloy. These materials are resistant to corrosion and can withstand the harsh conditions of the electrolysis process.

Membrane: Alkaline electrolyzers use a liquid KOH electrolyte, so they do not require a membrane.

Cell components: The cell components in alkaline electrolyzers, such as cell frames, separators, and pressure vessels, are typically made of materials such as stainless steel, carbon steel, or nickel alloys. These materials are resistant to corrosion and can withstand the harsh conditions of the electrolysis process.

Alkaline electrolyzers are a cost-effective and efficient option for hydrogen production. They have several advantages over other types of electrolyzers, including higher energy efficiency, low cost, high purity hydrogen production, and mechanical robustness. Alkaline electrolyzers are constructed using materials that are resistant to corrosion and can withstand the harsh conditions of the electrolysis process, such as nickel, nickel-plated steel, titanium coated with a nickel-based alloy, stainless steel, carbon steel, and nickel alloys. By utilizing alkaline electrolyzers, industries can produce high-purity hydrogen more efficiently and at a lower cost, contributing to a more sustainable and clean energy future.
